PE9660 CAD Drawing
2.92mm Female to 3.5mm Female Adapter

2. ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY TIME.
9999

1. UNLESS OTHERWISE SPECIFIED ALL DIMENSIONS ARE NOMINAL.
SIZE A

SCALE N/A

3. DIMENSIONS ARE IN INCHES [mm]. MMDDYY

.281 7.1 NOTES: CAD FILE

3.5mm FEMALE CAGE CODE 53919

FLATS PE9660
1/4 DWG TITLE

.752 19.1 REF. .600 15.2

.274 7 TYP. 2.92mm FEMALE R
THE ENGINEER'S RF SOURCE

.076 1.9 REF. Pasternack Enterprises, Inc. P.O. Box 16759 | Irvine | CA | 92623 Phone: (949) 261-1920 | Fax: (949) 261-7451 Website: www.pasternack.com | E-Mail: sales@pasternack.com
STANDARD TOLERANCES .X ±0.2 .XX ±0.01 .XXX ±0.005 *STANDARD TOLERANCES APPLY ONLY TO DIMENSIONS IN INCHES

PE9660 REV 1.1 4
