2.92mm Male to 2.92mm Female Radius
Right Angle Adapter, Up To 40 GHz
RF Adapters Technical Data Sheet PE91070
Humidity MIL-STD-202, Method 106
Shock MIL-STD-202, Method 213, Test Cond. I
Vibration MIL-STD-202, Method 204, Test Cond. D
Temperature Cycling MIL-STD-202, Method 102, Test Cond. C
Thermal Shock MIL-STD-202, Method 107, Test Cond. B
Salt Spray MIL-STD-202, Method 101, Test Cond. B
Compliance Certifications (see product page for current document)
Plotted and Other Data
Notes:
Typical Performance Data
dB Return Loss
0
-10
-20
-30
-40
-50
-60
-70
0 GHz 4 8 12 16 20 24 28 32 36 40
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications: 2.92mm Male to 2.92mm Female Radius Right Angle Adapter, Up To 40 GHz PE91070
