PE44663 MMCX plug surface mount PCB connector has an interface type of MMCX plug which is compatible with end launch cables and has an impedance of 50 Ohms. Pasternack's MMCX plug surface mount connector uses solder as an attachment method. Our plug MMCX PCB connector provides a maximum frequency of 6 GHz. Our high-quality radio frequency co-axial connector is used for general purpose test and printed circuit board applications. This MMCX plug RF connector is stocked to be readily available for same business day shipment and can be expertly assembled using our online Cable Creator.
The Pasternack MMCX plug surface mount PCB connector has a PTFE dielectric type and a VSWR of 1.5:1. Pasternack's MMCX PCB connector has a brass body with gold plating. Our PE44663 MMCX connector uses a gold-plated beryllium copper contact. This MMCX connector is suitable for applications including telecom and Wireless and applications requiring switching between internal and external circuits. Additional RF connector specs and dimensions for this component can be found on its PDF specification datasheet and CAD drawings above.
Our high-quality PE44663 features a 3 µin minimum body plating specification. The PE44663 MMCX surface mount connector operates at a temperature range of -55 to 155 deg C. This MMCX connector has a gold inner contact plating. The Pasternack MMCX plug connector has a maximum operating voltage of 170 Vrms. Our MMCX plug connector has a length of 0.346 inches, a width of 0.142 inches, and a weight of 0.006 lbs.
This Pasternack plug MMCX surface mount connector will ship the same business day as purchased. Our surface mount MMCX plug connector is part of over one million RF, microwave, and millimeter wave components in stock for local, domestic, and international shipment. For further information on similar products, our expert technical support and trained sales team can get you the ideal RF connector as per your requirements.
