0.5 Watt RF Load Up to 12.4 GHz With SMA Female Input Passivated Stainless Steel
Product ID:
PE6003
Key Specifications
Key Specifications (Click on Data Sheet Above for Additional Details). |
Termination Type | RF Load |
Connector Series | SMA |
Connector Gender | Female |
Minimum Frequency | DC |
Maximum Frequency | 12.4 GHz |
Impedance | 50 Ohm |
Maximum VSWR | 1.17:1 |
Maximum Power | 0.5 Watt |
Description
0.5 Watt RF Load Up to 12.4 GHz With SMA Female Input Passivated Stainless Steel
PE6003 0.5 Watts RF load (also known as termination or dummy load) has a SMA connector that is female. This Pasternack 0.5 watt SMA female load / termination is rated for a maximum frequency of 12.4 GHz. Our SMA female termination load is a rf load termination with a 50 Ohm impedance.
This SMA load / coax terminator is manufactured with no chain and passivated stainless steel body. Pasternack 50 Ohm SMA coaxial termination / load is RoHS compliant and has an average maximum VSWR of 1.17:1. PE6003 0.5 watt SMA female load termination is one of over 40,000 RF, microwave and millimeter wave components in-stock at Pasternack. Our SMA female 0.5 watt termination load will ship worldwide the same day as purchased.
