Part No.
Life Cycle
(Hrs)
Frequency
Band
Switch & Connector
Type
Features*
Isolation
(dB)
Insertion
Loss (dB)
Switching
Speed (ms)
Control
Voltage
(volts)
Power Rating
(watts)
USA & Canada +1 (866) 727-8376 International +1 (949) 261-1920
USA & Canada (866) 727-8376 International +1 (949) 261-1920
Part No.
Life Cycle
(Hrs)
Frequency
Band
Switch & Connector
Type
Features *
Isolation
(dB)
Insertion
Loss (dB)
Switching
Speed (ms)
Control
Voltage
(volts)
Power Rating
(watts)
PE71S6102 | 1M |
40 GHz |
SPDT |
F |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6103 | 1M |
40 GHz |
SPDT |
F |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6104 | 1M |
40 GHz |
SPDT |
I, F, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6105 | 1M |
40 GHz |
SPDT |
I, F, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6106 | 1M |
40 GHz |
SPDT |
L |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6107 | 1M |
40 GHz |
SPDT |
L |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6108 | 1M |
40 GHz |
SPDT |
I, L, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6109 | 1M |
40 GHz |
SPDT |
I, L, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6134 | 1M |
40 GHz |
SP4T |
N |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6135 | 1M |
40 GHz |
SP4T |
N |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6136 | 1M |
40 GHz |
SP4T |
N, I, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6137 | 1M |
40 GHz |
SP4T |
N, I, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6138 | 1M |
40 GHz |
SP4T |
L |
60 |
0.5 |
35 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6139 | 1M |
40 GHz |
SP4T |
L |
60 |
0.5 |
35 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6142 | 1M |
40 GHz |
SP6T |
N |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6143 | 1M |
40 GHz |
SP6T |
N |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6144 | 1M |
40 GHz |
SP6T |
N, I, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6145 | 1M |
40 GHz |
SP6T |
N, I, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6146 | 1M |
40 GHz |
SP6T |
L |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6147 | 1M |
40 GHz |
SP6T |
L |
60 |
0.5 |
35 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6148 | 1M |
40 GHz |
SP6T |
L, I, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6149 | 1M |
40 GHz |
SP6T |
L, I, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6118 | 1M |
40 GHz |
Transfer |
F |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6119 | 1M |
40 GHz |
Transfer |
F |
60 |
0.5 |
20 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6120 | 1M |
40 GHz |
Transfer |
I, F, TTL |
60 |
0.5 |
20 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6121 | 1M |
40 GHz |
Transfer |
I, F, TTL |
60 |
0.5 |
20 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6122 | 1M |
40 GHz |
Transfer |
L |
60 |
0.5 |
20 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6123 | 1M |
40 GHz |
Transfer |
L |
60 |
0.5 |
20 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6124 | 1M |
40 GHz |
Transfer |
I, L, TTL |
60 |
0.5 |
20 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6125 | 1M |
40 GHz |
Transfer |
I, L, TTL |
60 |
0.5 |
20 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6140 | 1M |
46 GHz |
SP4T |
L, I, TTL |
60 |
0.5 |
15 |
12 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
PE71S6141 | 1M |
46 GHz |
SP4T |
L, I, TTL |
60 |
0.5 |
15 |
28 |
10 |
|
Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
* Features:
I = Indicators
F = Failsafe
L = Latching Feature
TTL = TTL Control Feature
N = Normally Open
S = Self Cutoff
T = Terminated
H = Hot Switching
P = Pulse Latching
